Fusion

Next-generation All-In-One DVLED engineered for maximum impact

Key Features

Fusion Series

The SBC Fusion Series is a premium line of All-In-One DVLED displays that brings the future of visual communication directly into your space. Available with COB technology, Fusion offers exceptional clarity, streamlined installation, and ADA-compliant design. Its ultra-thin bezels, intuitive control system, and fully integrated processing make it ideal for environments where ease of use, reliability, and stunning picture performance are essential. Whether powering boardrooms, classrooms, retail experiences, or public signage, Fusion delivers Vision in Every Pixel.

All-In-One Simplicity

Fusion’s highly integrated design eliminates the complexity traditionally associated with DVLED installations. Each display includes onboard processing, multiple input options, front maintenance access, and a single-button power interface—making operation as easy as a commercial display and installation dramatically faster.

Precision Image Quality in COB

Get the performance level your application demands.Fusion COB offers enhanced contrast, smooth surface finish, higher durability, and ≥600 nits brightness for premium applications requiring superior black levels.

Reliable Performance for Demanding Environments

With a wide operating range (14°F–105°F), IP43 rating, and certifications including CCC, CE, FCC, and ETL, Fusion is built for reliability. The COB series offers additional durability through a smooth, impact-resistant surface.

COB All-In-One Fusion

View Specifications

Why Choose the Fusion Series?

The Fusion Series is engineered for professionals who expect more from their visual technology. Built on SBC’s legacy of innovation, Fusion combines All-In-One simplicity with premium LED performance, available in COB configurations. Whether you’re designing a boardroom, outfitting a lecture hall, or elevating a retail environment, Fusion delivers a level of reliability, clarity, and ease-of-use that outperforms traditional displays and competing DVLED systems.

Pure Performance

Engineered to deliver exceptional clarity, contrast, and reliability in any professional environment.

Effortless Integration

A fully unified All-In-One system that installs fast, operates simply, and fits seamlessly into modern spaces.

Future-Ready

Designed with advanced COB technology to elevate today’s experiences and support tomorrow’s demands.

SBC COB All-In-One Fusion

ModelSBC Fusion 108 COBSBC Fusion 135 COBSBC Fusion 163 COB
LED ConfigurationCOBCOBCOB
Pixel Pitch (mm)1.251.561.875
Pixel Density (dots/m²)640,000410,913284,444
Module Size (WxH, mm)150 x 168.75
Module Resolutions (dots)16,20010,3687,200
Cabinet Size (WxH, mm)600 x 337.5
Cabinet Resolutions (dots)480 x 270384 x 216320 x 180
Cabinet Quantity (WxH, pcs)4 x 4 = 165 x 5 = 256 x 6 = 36
Screen Size (WxH, mm)2400 x 1350 (108")3000 x 1687.5 (135")3600 x 2025 (163")
Bezel Size5mm
Power Max / Avg1120W / 512W1750W / 800W2415W / 1086W
Screen Resolution (dots)1920 x 1080
Best Viewing Angle (H/V, °)170 / 160
Min Viewing Distance (ft)4~15
Contrast10,000:1
Input Max3840 x 2160 @60hz
Refresh Rate (Hz)≥3840HZ
Brightness (nits)≥600
Color Bit Depth8
Grayscale Level (levels)256
Grayscale Bit Depth14
Color Temperature (K)6500K
Operating Temperature14F - 105F (-10°C - 40°C)
Operating Humidity10 ~ 90% no condensation
Storage Temperature-40F - 140F (-40°C - 60°C)
Storage Humidity10 ~ 90% no condensation
IP RatingIP43
CertificationsCCC, CE, FCC, ETL
Maintenance MethodFront Maintenance
Input / Output2x HDMI2.0, 1xDisplayPort 1.2, 1xRS232(viaRJ45), 1x3.5mm Audio Out (Fixed / Variable), 1x3.5mm AV input, 2xUSB2.0 (Service only), 1 or 2 Locking Power Input
